A DC/DC converter is an essential component in any new energy vehicle.
In new energy vehicles, since traditional low-voltage generator assemblies cannot function properly, a DC/DC converter must be installed. This converter draws power from the vehicle's main battery pack to charge the onboard 12V or 28V low-voltage battery and provides all low-voltage power supply for the entire vehicle.
CDU stands for Conversion & Distribution Unit, referring to an integrated high-voltage “electrical control” system that combines functions such as the DC/DC converter, onboard charger, and high-voltage junction box. CDU system integration is categorized into “two-in-one,” “three-in-one,” and “multi-in-one” assemblies. It is increasingly adopted by domestic and international OEMs and has become one of the global mainstream technologies.
In new energy vehicles, since traditional low-voltage generator assemblies cannot function properly, a DC/DC converter must be installed. This converter draws power from the vehicle's main battery pack to charge the onboard 12V or 28V low-voltage battery and provides all low-voltage power supply for the entire vehicle.
CDU stands for Conversion & Distribution Unit, referring to an integrated high-voltage “electrical control” system that combines functions such as the DC/DC converter, onboard charger, and high-voltage junction box. CDU system integration is categorized into “two-in-one,” “three-in-one,” and “multi-in-one” assemblies. It is increasingly adopted by domestic and international OEMs and has become one of the global mainstream technologies.
System Diagram
Innovative R&D
Over 700 R&D engineers, with more than 80% holding bachelor's degrees or higher, over 5,000 case studies, more than 300 patented technologies, and over 200 classic circuit designs and methodologies. Safety Testing Lab, EMC Testing Lab, HALT/HASS Testing Lab, PLD Testing Lab, Lightning Strike Testing Lab, Air Tightness Testing Lab, Environmental Testing Lab, ROHS Testing Lab, Salt Spray Testing Lab, Mechanical Testing Lab
Smart Manufacturing
Monthly production capacity of 1 million units, with a market return rate ≤200PPM; refined PCB processes, SMT solder joint DPPM below 40ppm; advanced reflow soldering needle technology ensuring superior weld quality and high production efficiency;
Patented core reflow oven curing technology enables streamlined operations; comprehensive production equipment ensures efficiency and product consistency; fully automated testing systems effectively reduce market DPPM;
In-house developed electronic feedback load and real-time aging monitoring systems; process integration during design phase enhances product manufacturability; small-batch production validation ensures overall first-pass yield.
Related Products
-
On-Board Charger (OBC) 20kWThis product is a 20kW three-phase four-wire vehicle charger with an input voltage range of 323-437Vac and a high-voltage output range of 330-554Vdc. It supports single-phase input with a voltage range of 187-253Vac, delivering a maximum output power of 6.6kW under single-phase input. It supports constant current charging, constant voltage charging, and constant power charging modes. Utilizing mature soft-switching technology internally, it features a compact structure, high efficiency, -
12kW On-Board DC/DC Power SupplyThis product operates within an input voltage range of 450–900 Vdc, with a rated output of 27.8 Vdc/12 kW. It employs water-cooled heat dissipation and features input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, overtemperature protection, and CAN communication functionality. Suitable for various new energy vehicles including pure electric, hybrid, and range-extended models. -
2.5kW Vehicle-Mounted DC/DC Power SupplyThis product operates within an input voltage range of 400–850 Vdc, delivering a rated output of 13.5 Vdc/2500 W (peak power 3000 W, duration 6 min). It employs system fan cooling and incorporates multiple protection features: input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, and overtemperature protection. Suitable for various new energy vehicles including pure electric, hybrid, -
4.5kW Vehicle-Mounted DC/DC Power SupplyThis product operates within an input voltage range of 400–800 Vdc, delivering a rated output of 27.5 Vdc/4500 W (peak power 5000 W). It features integrated system cooling, input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, overtemperature protection, and CAN communication functionality. Suitable for various new energy vehicles including pure electric and range-extended models. -
6kW Vehicle-Mounted DC/DC Power SupplyThis product operates within an input voltage range of 450–1000 Vdc, delivering a rated output of 27.8 Vdc/6000 W (peak power 6600 W). It features integrated system cooling, input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, overtemperature protection, CAN communication, and scheduled wake-up functionality. -
6kW Vehicle-Mounted DC/DC Power SupplyThis product operates within an input voltage range of 550–950 Vdc, delivering a rated output of 27.8 Vdc/6000 W (peak power 6600 W). It features integrated liquid cooling for thermal management, along with input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, overtemperature protection, CAN communication, and scheduled wake-up functionality. Suitable for various new energy vehicles including
-
6kW Vehicle-Mounted DC/DC Power SupplyThis product operates within an input voltage range of 400–950 Vdc, delivering a rated output of 27.5 Vdc/6000 W (peak power 6600 W). It features integrated liquid cooling for thermal management, along with input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, overtemperature protection, CAN communication, and scheduled wake-up functionality. Suitable for various new energy vehicles including -
4.5kW Vehicle-Mounted DC/DC Power SupplyThis product operates within an input voltage range of 400–800 Vdc, delivering a rated output of 27.8 Vdc/4500 W (peak power 5000 W). It features integrated system cooling, input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, overtemperature protection, and CAN communication functionality. Suitable for various new energy vehicles including pure electric and range-extended models. -
3kW Vehicle-Mounted DC/DC Power SupplyThis product operates within an input voltage range of 400–950 Vdc, delivering a rated output of 27.5 Vdc/3025 W (peak power 3600 W). It features integrated system cooling, input overvoltage/undervoltage alarm and protection, output overcurrent alarm and protection, output overvoltage protection, output short-circuit protection, overtemperature protection, and CAN communication functionality. Suitable for various new energy vehicles including pure electric and range-extended models.
